XLamp® XP-C LED
Lighting-Class Performance, Small Package
The XLamp XP-C LED combines the proven lighting-class performance and reliability of the XLamp XR-E LED in a package with 80% smaller footprint. This smaller package extends Cree’s award-winning LED performance into new LED lighting applications.
Features
- Symmetrical package
- Unlimited floor life at <= 30 degrees C/85% RH
- Electrically-isolated thermal path
Lighting Applications
- Portable
- Backlighting
- Signage
- Retail display
Documentation
Product Selector
| White |
CCT (K) |
Max Current (mA) |
Viewing Angle (°) |
Standard Min. Flux @ 350 mA |
Product Status |
| Cool |
10,000 – 5,000 |
500 |
115 |
100 lm
93.9 lm
87.4 lm
80.6 lm
|
Active |
| Neutral |
5,000 – 3,700 |
500 |
115 |
87.4 lm
80.6 lm
73.9 lm
67.2 lm
|
Active |
| Warm |
3,700 – 2,600 |
500 |
115 |
80.6 lm
73.9 lm
67.2 lm
62.0 lm
56.8 lm
|
Active |
| Color |
DWL (nm) |
Max Current (mA) |
Viewing Angle (°) |
Standard Min. Flux @ 350 mA |
Product Status |
| Royal Blue |
450-465 |
500 |
125 |
300 mW
250 mW |
Active |
| Blue |
465-485 |
500 |
125 |
18.1 lm
13.9 lm |
Active |
| Green |
520-535 |
500 |
125 |
73.9 lm
67.2 lm
62.0 lm
56.8 lm
51.7 lm |
Active |
| Amber |
586-595 |
350 |
125 |
51.7 lm
45.7 lm
39.8 lm
35.2 lm |
Active |
| Red-Orange |
610-620 |
350 |
125 |
56.8 lm
51.7 lm
45.7 lm
39.8 lm |
Active |
| Red |
620-630 |
350 |
130 |
45.7 lm
39.8 lm
35.2 lm
30.6 lm |
Active |
Application Notes
Product Cut Sheets
Design Files
| Design Type |
LED Type |
File Type |
Link |
| Optical Source Model |
XLamp XP-C White
|
ProSource 7 (rs7) |
|
IES |
|
XLamp XP-C Royal Blue |
ProSource 8 (rs8) |
|
XLamp XP-C Blue |
ProSource 8 (rs8) |
|
XLamp XP-C Red |
ProSource 8 (rs8) |
|
XLamp XP-C Green |
ProSource 8 (rs8) |
|
XLamp XP-C Amber |
ProSource 8 (rs8) |
|
| Star PCB |
XLamp XP-C |
Gerber |
|
| 3D Model |
XLamp XP-C |
STEP |
|
|
